14" METAL CUTTING MITERING CHOP SAW - S14MCS

Brand:
EVOLUTION POWER TOOLS

Features:
The S14MCS incorporates key improvements for even greater performance and precision:

EVOMAX 15A Smart Motor: The EVOMAX smart motor actively optimizes blade speed, extending blade life by up to 30% and reducing your cost per cut. Soft start limits inrush currents, preventing tripped breakers and reducing mechanical stress, which extends motor life. The electronic blade brake stops the blade in seconds for safer and faster work.

Ultra-Long-Life EVOMAX Blade: Supplied with the EVOMAX mild steel blade, designed to perform over 3,500 cuts in 101.6 mm x 3.2 mm (4" x 1/8") mild steel round tubing—50% more than the leading competitor’s blade. Its 80 cermet carbide teeth deliver cleaner, more precise cuts throughout the blade’s lifespan. Handmade in Japan for unmatched quality.

Shadow Line Cutting Guide: Designed for optimal accuracy, the S14MCS cold-cut miter saw features a shadow line cutting guide that clearly indicates the cutting area, making alignment precise. Unlike a laser guide, the LED works in all environments and remains perfectly aligned.

Reinforced Fence and Base: A ¼-inch steel plate strengthens the fence to prevent flex under heavy clamping, while structural ribs reinforce the base.

• Unlockable miter handle
• Cold-cut technology – Cuts metal 4x faster than an abrasive saw and allows direct welding after cutting. Unbreakable blade, zero dust inhalation.
• Precise miter cuts with +/-46° miter table, stops at common angles, and an accurate stainless steel miter guide.
• EVOMAX 15A smart motor extends blade life by 30%, reducing your cost per cut.
• EVOMAX Ultra Long Life cermet carbide blade included – 50% longer life than the leading competitor.
• Shadow line cutting guide clearly marks the blade path for fast, accurate alignment.
• More robust than ever – Reinforcements added to fence and base eliminate flex under heavy clamping.
• Dual front sliding clamp with three-axis movement for secure clamping of any shape or size.
• Quick-release clamping systems and tool-free adjustments for fast setup.
• Heavy-duty construction with ACME threaded clamps, all-metal blade guard, and cast alloy base.
• Three-position cutting head allows forward blade offset for optimized cut path and extended blade life.
• Soft start prevents inrush current, reducing breaker trips and extending motor life.
• Electronic blade brake stops the blade in seconds.
• Integrated hex key storage for quick blade changes.
• Knurled guide and clamping surface provide firm grip on the workpiece for optimal accuracy.
• Ergonomic horizontal handle and trigger for all-day comfort.
• 3-year warranty.

Specifications:
• Voltage (120 V 60 Hz): 15 A
• No-load speed: 1100 RPM
• Max miter (left and right): +/- 46°
• Rubber cord: 3 meters / 10 feet
• Blade diameter: 14 in
• Arbor: 1 in

Cutting Capacities:
• Mild steel plate (max thickness): 1/2"
• Stainless steel plate (max thickness): 13/64"
• Square tube at 90° (mild steel): 4-3/4" x 4-3/4"
• Square tube at 45° ML: 3-15/16" x 3-15/16"
• Square tube at 45° MR: 1-11/16" x 1-11/16"
• Rectangular tube at 90° (mild steel): 6-1/2" x 3-15/16"
• Rectangular tube at 45° (mild steel): 3-15/16" x 4-5/16"
• Round tube at 90° (mild steel): 4-3/4"
• Round tube at 45° (mild steel): 4-5/16"
• Minimum workpiece length: 5/16"

Includes:
• (1) Evolution S14MCS Cold-Cut Miter Saw
• (1) 80-tooth TCT mild steel blade
• (1) 5 mm / 8 mm double hex key
• (1) Cutting head assembly
• (1) Base table assembly
• (1) Rear stabilizer foot
• (1) Quick-release upper clamp
• (1) Rail support and fixings
• (3) V-blocks
• (2) Quick-release front clamps
